Stainless Steel Heat Exchanger, 60 Pcs Stainless Steel Heat Exchanger Brazed Plate Type Water Heater 304 Stainless Steel for Home Brewing Beer

Brazed Plate Heat Exchanger 60 plates Water heater Stainless Steel Small size high efficiency heat exchanger Recirculating chiller Tap water interface: 20mm outer diameter Heating interface:25mm outer diameter selection (if you need 32mm outer diameter, leave a message to inform us of the interface caliber) Name: Brazed plate type heat exchanger Material:SUS 304 Stainless Steel, food grade WeldIing Material: 99.9% Copper Application:Home Brew Wort Chiller, Famliy Hot Water supply Thread of Port A1、A2:1/2" BSPT Male Thread of Port B1、B2:1" BSPT Male Plates Number: 60 plates Dimension:195x85x310mm Heat Transfer Area/plate: 0.028 m2(0.30 ft2) Thickness of One Plate:0.25-0.35mm Working Temperature:-160 ℃ to + 185 ℃ Below 50 plates: suitable for washing hands and face 60-80 plates: suitable for kitchen washing dishes and dishes. 100-120 plates: can support bathing, mainly depends on the heat source's ability to supply heat. Heat exchange rate: 85% Heat source heating capacity> 50 ° C hot water temperature, comfortable bathing Heat source heating capacity <50 ° C, hot water temperature, average bathing experience (winter) Options Instruction: Same side: mean the 4 ports are in the same side Different side: mean the 4 ports are in different side, each side with 2 ports. Please choose it according to your own demand. Thanks. Besides above four ports, there is an air vent on the heat exchanger for 50 plates heat exchanger and above, this air vent's function is to avoid if there is some air remained in the exchanger and you need to release the remain air so that the water can go through when you first time use this heat exchanger. For other time, the air vent need to be plugged

• 【High Heat Transfer Efficiency】There are many staggered plates inside the plate heat exchanger, which increases the heat transfer area and thus improves the heat transfer efficiency.
• 【Compact Design】compared with the traditional tube heat exchanger, the plate heat exchanger is small in size and occupies less space, which can save space
• 【Convenient for Use】Thread makes a easy, quick, flexible hookup. Highly conductive and super-thin stainless steel plates make good performance and economy for heating transfer and cooling
• 【Quality Materials】 This chiller is made of 60 plates of 304 stainless steel that have been brazed together with pure copper in an oxygen-free furnace.
• 【Wide Range of Applications】Suitable for a wide range of living scenarios Home Brew Wort Chiller.
